Type

Structure type

Vehicular

Function

Servo tracking

Position,velocity, sway

Table size

φ320mm

Countertop material

Super hard aluminum alloy

Carrying capacity

40kg

30kg

Flatness

0.01mm

Runout

0.02mm

Swing accuracy

±2"

Angular position accuracy

±10"

±3"

Angular position range

Continuous rotation

Angular acceleration

≥100°/S²

300°/S²

Speed accuracy

2x10-5(360°average)

2x10-4(10°average)

2x10-3(1°average)

Position resolution

0.36"

Rate range

0.001°/S~300°/S

0.001°/S~1000°/S

Swing range

0°~±45°

Swing cycle

2s~20s

User slip

Ring

30rings customized

Interface

RS232/RS422/ Ethernet

With

thermostat

NO

Test object

Dynamic target

Gyroscope accelerometer
